Product Summary
The MAX7317AEE+ is a 10－port spi－interfaced i/o expander.The MAX7317AEE+ serial－interfaced peripheral provides microprocessors with 10 I/O ports rated to 7V. Each port can be individually configured as either an opendrain output, or an overvoltage－protected Schmitt input. The MAX7317AEE+ supports hot insertion. All port pins remain high impedance in power－down (V+ = 0V) with up to 8V asserted on them. The MAX7317AEE+ is available in 16－pin thin QFN and QSOP packages and operates in the －40°C to +125°C range. For a similar part with constant－current outputs and 8－bit PWM controls, refer to the MAX6966/MAX6967 data sheet.
Parametrics
MAX7317AEE+ absolute maximum ratings: (1)Voltage (with respect to GND) V+: －0.3V to +4V; (2)SCLK, DIN, CS, DOUT: －0.3V to (V+ + 0.3V); (3)P－: －0.3V to +8V; (4)DC Current in P－: 24mA; (5)DC Current into DOUT: 10mA; (6)Total GND Current: 200mA.
Features
MAX7317AEE+ features: (1) High－Speed, 26MHz SPI.－/QSPI－./MICROWIRE.－ Compatible Serial Interface; (2) 2.25V to 3.6V Operation; (3) I/O Port Inputs are Overvoltage Protected to 7V; (4) I/O Port Outputs are 7V－Rated Open Drain; (5) I/O Ports Support Hot Insertion; (6) 0.7μA (typ), 1.9μA (max) Standby Current; (7) Tiny 3mm x 3mm, 0.8mm High Thin QFN Package; (8) －40℃to +125℃ Temperature Range.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MAX7317AEE+ |
Maxim Integrated Products |
I/O Expanders, Repeaters & Hubs 10-Bit I/O Port Expander |
Data Sheet |
|
|
||||||||||||
|
MAX7317AEE+T |
Maxim Integrated Products |
I/O Expanders, Repeaters & Hubs 10-Bit I/O Port Expander |
Data Sheet |
|
|
||||||||||||
