Product Summary
The SKKT106B/16E is a thyristor / diode module.
Parametrics
SKKT106B/16E absolute maximum ratings: (1)IL Tvj = 25 °C; RG = 33 W; typ./max.: 300 / 600A; (2)rT Tvj = 130 °C: 2mΩ; (3)IGT Tvj = 25 °C; d.c.: 150mA; (4)ITAV sin. 180; Tcase = 85 °C: 160A.
Features
SKKT106B/16E features of A5841SLW: (1)Heat transfer through aluminium oxide ceramic isolated metal baseplate; (2)Hard soldered joints for high reliability; (3)UL recognized, file no. E 63 532.
Diagrams
 |
